FRONT FORK / TRIPLE CLAMP

FRONT FORK (PARTS) FOR HVA 701 ENDURO 2019

HANDLEBAR / CONTROLS

(1) 48601713S1

AXLE CLAMP R/S + TUBE D48MM 35

(2) 48601712S1

AXLE CLAMP L/S + TUBE D48MM 35

(3) 48600736

FORK OUTER TUBE 49,13X577 DT54

(4) 91410065S

SPRING D43.2L465 5.4N/MM D5.25

(5) 48600456

WASHER 35X43X2,5 PLASTIC

(5) 48600457

PRELOAD BUSH 35X43X3,5

(5) 48600458

WASHER 35X43X1,5 PLASTIC

(6) 48601960S1

(7) 48601961S1

(8) R14033

SCREW CAP SMALL PART KIT

(9) 48600048

O-RING 46X2 NBR70 SILICONIZED

(9) 48600048

O-RING 46X2 NBR70 SILICONIZED

(10) RP10048T

SEALKIT 48MM SKF BLACK

(11) R14047T

GUIDE BUSHING SET FORK 48MM

(12) 43570787S1

TUBE CPL.

(13) 43570787S2

TUBE D23X462 CPL.

(14) 48600430

GUIDE BUSHING 12X14X10

(14) 48600430

GUIDE BUSHING 12X14X10

(15) 48600885

NUT VALVE M6X0,5 H6,5 WAF17

(16) 40540486

NUT M6X0,5 H6,5 WAF10 REBOUND

(17) 48602002S

MIDVALVE PISTON ASSEMBLY D23

(17) 48602002S

MIDVALVE PISTON ASSEMBLY D23

(18) 48600382

SPRING (11,4) 0,4-8 VALVE

(19) 48600576

TAP 6X46 REBOUND

(20) 48600299

O-RING 6X1,2 NBR70

(20) 48600299

O-RING 6X1,2 NBR70

(21) 48600578S

SPRING (13,9) 37-32 REBOUND CP

(22) 48601298

SPRING RETAINER 27,08X43X45

(23) 48600277S

NEEDLE 4,5X43,6 CPL.

(24) 48600887S

NEEDLE 4,5X43,6 CPL.

(25) 48600571

PISTON ROD 12X549

(26) 48600559

ADJUSTMENT TUBE 6X520

(27) 48601556S3

(28) 48600163

NUT VALVE M6X0,5 H6,5 WAF17

(29) 48600202

SPRING (8,5) L6,5 VALVE

(29) 48600202

SPRING (8,5) L6,5 VALVE

(30) 48601934S

PISTON 6X27,3X9 COMPRESSION CP

(31) 48601553S

SCREW CAP M29,3X1 OC SPLIT CPL

(32) 04500003

O-RING 11X2,5 NBR70 PTFE YELLO

(33) 48601702

SHIM 27,5X33X0,3

(34) 0025080256

HH COLLAR SCREW M8X25

(36) 48602007

STROKE INDICATOR 48MM RED

(37) 48601948

FORK PROTECTION RING 60,1MM

(38) 48601086

TAP 6X45 COMPRESSION

(39) 48601980S

SCREW CAP M29,3X1

(98) T14034

FUCHS GREASE IPR (250G)

(99) 48601166S1

FORK OIL SAE4 5L

	Part number	Description	Qty
# 1	48601713S1	AXLE CLAMP R/S + TUBE D48MM 35	425,92 €(364,77 £)
# 2	48601712S1	AXLE CLAMP L/S + TUBE D48MM 35	425,92 €(364,77 £)
# 3	48600736	FORK OUTER TUBE 49, 13X577 DT54	296,81 €(254,20 £)
# 4	91410065S	SPRING D43.2L465 5.4N/MM D5.25	Contact	0,00 €(0,00 £)
# 5	48600456	WASHER 35X43X2, 5 PLASTIC	4,11 €(3,52 £)
# 5	48600457	PRELOAD BUSH 35X43X3, 5	4,11 €(3,52 £)
# 5	48600458	WASHER 35X43X1, 5 PLASTIC	4,11 €(3,52 £)
# 6	48601960S1	48601960S1	Contact	0,00 €(0,00 £)
# 7	48601961S1	48601961S1	Contact	0,00 €(0,00 £)
# 8	R14033	SCREW CAP SMALL PART KIT	15,43 €(13,21 £)
# 9	48600048	O-RING 46X2 NBR70 SILICONIZED	1,75 €(1,50 £)
# 10	RP10012 RP10048T	SEALKIT 48MM SKF BLACK	70,91 €(60,73 £)
# 11	R14047 R14047T	GUIDE BUSHING SET FORK 48MM	32,19 €(27,57 £)
# 12	43570787S1	TUBE CPL.	150,40 €(128,81 £)
# 13	43570787S2	TUBE D23X462 CPL.	150,40 €(128,81 £)
# 14	48600430	GUIDE BUSHING 12X14X10	6,96 €(5,96 £)
# 15	48600885	NUT VALVE M6X0, 5 H6, 5 WAF17	4,11 €(3,52 £)
# 16	40540486	NUT M6X0, 5 H6, 5 WAF10 REBOUND	4,11 €(3,52 £)
# 17	48602002S	MIDVALVE PISTON ASSEMBLY D23	21,78 €(18,65 £)
# 18	48600382	SPRING (11, 4) 0, 4-8 VALVE	4,11 €(3,52 £)
# 19	48600576	TAP 6X46 REBOUND	11,62 €(9,95 £)
# 20	48600299	O-RING 6X1, 2 NBR70	1,21 €(1,04 £)
# 21	48600578S	SPRING (13, 9) 37-32 REBOUND CP	21,78 €(18,65 £)
# 22	48601298	SPRING RETAINER 27, 08X43X45	19,30 €(16,53 £)
# 23	48600277S	NEEDLE 4, 5X43, 6 CPL.	10,04 €(8,60 £)
# 24	48600887S	NEEDLE 4, 5X43, 6 CPL.	Contact	0,00 €(0,00 £)
# 25	48600571	PISTON ROD 12X549	102,37 €(87,67 £)
# 26	48600559	ADJUSTMENT TUBE 6X520	21,78 €(18,65 £)
# 27	48601556S3	48601556S3	Contact	0,00 €(0,00 £)
# 28	48600163	NUT VALVE M6X0, 5 H6, 5 WAF17	4,11 €(3,52 £)
# 29	48600202	SPRING (8, 5) L6, 5 VALVE	4,11 €(3,52 £)
# 30	48601934S	PISTON 6X27, 3X9 COMPRESSION CP	21,78 €(18,65 £)
# 31	48601553S	SCREW CAP M29, 3X1 OC SPLIT CPL	21,78 €(18,65 £)
# 32	04500003	O-RING 11X2, 5 NBR70 PTFE YELLO	1,21 €(1,04 £)
# 33	48601702	SHIM 27, 5X33X0, 3	2,36 €(2,02 £)
# 34	0025080256	HH COLLAR SCREW M8X25	3,03 €(2,59 £)
# 36	48602007	STROKE INDICATOR 48MM RED	6,96 €(5,96 £)
# 37	48601948	FORK PROTECTION RING 60, 1MM	8,53 €(7,31 £)
# 38	48601086	TAP 6X45 COMPRESSION	Contact	0,00 €(0,00 £)
# 39	48601980S	SCREW CAP M29, 3X1	21,78 €(18,65 £)
# 98	T14034	FUCHS GREASE IPR (250G)	34,97 €(29,95 £)
# 99	48601166S1	FORK OIL SAE4 5L	111,50 €(95,49 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Husqvarna. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Husqvarna, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
