CYLINDER

CRANKSHAFT / PISTON FOR HUSQVARNA TC 85 19/16 2020

REED VALVE CASE

Item numbers

PISTON CPL. I

47230007100I

Contact

PISTON CPL. II

47230007100II

Contact

PISTON RING 85 SX 2003

47030030000

21,84 €(19,24 £)

Unit Price Incl. Tax

PISTON PIN

47230033000

14,10 €(12,42 £)

Unit Price Incl. Tax

WIRE LOCK RING 85 SX 2003

47030074000

3,87 €(3,41 £)

Unit Price Incl. Tax

NUT, PRIMARY GEAR

47230029000

0910001400600S

9,62 €(8,48 £)

Unit Price Incl. Tax

DETENT EDGED RING M14

47230029014

1,45 €(1,28 £)

Unit Price Incl. Tax

O-RING 21, 00X2, 00 NBR70

0770210020

0770021020

1,33 €(1,17 £)

Unit Price Incl. Tax

OIL SEAL

0760304261

5,69 €(5,01 £)

Unit Price Incl. Tax

BALL BEARING 22X52X15

47030083000

16,94 €(14,92 £)

Unit Price Incl. Tax

WOODRUFF KEY DIN6888-3X3, 7

0888030037

0,97 €(0,85 £)

Unit Price Incl. Tax

CRANKSHAFT CPL.

47230018000

47230018100

475,17 €(418,62 £)

Unit Price Incl. Tax

NEEDLE BEARING KBK 14X18X17 03

47030034000

22,14 €(19,51 £)

Unit Price Incl. Tax

WOODRUFF KEY DIN6888-3X5X13

0888030050

0,97 €(0,85 £)

Unit Price Incl. Tax

CYLINDRICAL ROLLER BEARING NJ2

49030023000

56,20 €(49,51 £)

Unit Price Incl. Tax

SEAL SHAFT RING 20X35X6 BTSL

47030076100

6,72 €(5,92 £)

Unit Price Incl. Tax

LOCKING RING VSK 12

50230029012

Contact

COLLAR NUT, M12X1, RIGHT

49030021000

49030021100

7,93 €(6,99 £)

Unit Price Incl. Tax

REPAIR KIT

47030015300

47230015044

129,59 €(114,17 £)

Unit Price Incl. Tax

CRANKSHAFT REPAIR KIT

00050002318

47230018188

79,44 €(69,99 £)

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Husqvarna. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CRANKSHAFT / PISTON of your Husqvarna TC 85 19/16 of 2020. Let us know if you have any questions.
