FRONT FORK / TRIPLE CLAMP

FRONT FORK (PARTS) FOR HUSQVARNA FE 570 2011

WP SHIMS FOR SETTING

Item numbers

ADJUSTER COMPRESSION CPL.

48600811S

48600811ST

5,63 €(4,93 £)

Unit Price Incl. Tax

FORK OUTER TUBE 49, 13X577 DT54

48600736

305,77 €(268,01 £)

Unit Price Incl. Tax

FORK PROTECTION RING 62, 1MM

48600698

8,77 €(7,69 £)

Unit Price Incl. Tax

GUIDE BUSHING 48X52X12

48600429

48601009

10,41 €(9,12 £)

Unit Price Incl. Tax

SUPPORTWASHER 50X57, 6X1, 5

48600013

5,63 €(4,93 £)

Unit Price Incl. Tax

SHAFT SEAL SKF 48X58X11, 4 BLACK

48600969

S604800001000C1

17,30 €(15,16 £)

Unit Price Incl. Tax

SNAP RING SB58X1, 5 ACC DRAWING

48600070

3,57 €(3,13 £)

Unit Price Incl. Tax

DIRTSCARPER SKF 48MM BLACK

48600968

S604800000000C1

17,30 €(15,16 £)

Unit Price Incl. Tax

GUIDE BUSHING 47X49X20

48600428

48601008

10,41 €(9,12 £)

Unit Price Incl. Tax

MEMBRANE 11, 2X37X112

48600281

32,43 €(28,42 £)

Unit Price Incl. Tax

O-RING 9, 5X1, 5 NBR70 YELLOW

48600301

1,27 €(1,11 £)

Unit Price Incl. Tax

O-RING 17X2 70 SH NBR BLACK

46810811

1,27 €(1,11 £)

Unit Price Incl. Tax

SCREW BUSH M20X1 L=33 CPL.

48600280S

32,43 €(28,42 £)

Unit Price Incl. Tax

COPPER DISC 20, 5X26X1

48600275

1,57 €(1,38 £)

Unit Price Incl. Tax

ADJUSTMENT TUBE 6X371

48600269

22,51 €(19,73 £)

Unit Price Incl. Tax

PISTON ROD 12X405

48600464

Contact

LOCK NUT M12X1 H23 WAF17

48600459

8,77 €(7,69 £)

Unit Price Incl. Tax

NEEDLE 4, 5X43, 6 REBOUND

48600887

10,41 €(9,12 £)

Unit Price Incl. Tax

O-RING 2X1, 5 NBR70

48600298

1,27 €(1,11 £)

Unit Price Incl. Tax

SPRING (5, 4) 4-23 REBOUND

48600444

4,36 €(3,82 £)

Unit Price Incl. Tax

SPRING 4, 8N/MM SET D=5, 25 MM

91410020S

111,08 €(97,36 £)

Unit Price Incl. Tax

SPRING 4, 4 N/MM SET D=5, 1MM

91410027S

111,08 €(97,36 £)

Unit Price Incl. Tax

SPRING 4, 6 N/MM SET D=5, 1MM

91410028S

111,08 €(97,36 £)

Unit Price Incl. Tax

WASHER 35X43X2, 5 PLASTIC

48600456

4,36 €(3,82 £)

Unit Price Incl. Tax

PRELOAD BUSH 35X43X3, 5

48600457

4,36 €(3,82 £)

Unit Price Incl. Tax

WASHER 35X43X1, 5 PLASTIC

48600458

4,36 €(3,82 £)

Unit Price Incl. Tax

SPRING RETAINER 12, 3X19X1, 25 R

48600525

10,41 €(9,12 £)

Unit Price Incl. Tax

SPRING SUPPORT RING 27, 08X42X4

48600520

27,47 €(24,08 £)

Unit Price Incl. Tax

O-RING 6X1, 2 NBR70

48600299

1,27 €(1,11 £)

Unit Price Incl. Tax

SPRING (13, 9) 37-32 REBOUND

48600578

12,04 €(10,55 £)

Unit Price Incl. Tax

TAP 6X46 REBOUND

48600576

12,04 €(10,55 £)

Unit Price Incl. Tax

SPRING (11, 4) 0, 4-8 VALVE

48600382

4,36 €(3,82 £)

Unit Price Incl. Tax

MEMBRANE HOLDER WP

48600519S3

48600519E3

254,58 €(223,14 £)

Unit Price Incl. Tax

ROUND-WIRE SNAP RING 28, 5X1, 5

48600512

3,03 €(2,66 £)

Unit Price Incl. Tax

HS COUNTERSUNK HEAD SCREW M4X6

48600542

2,54 €(2,23 £)

Unit Price Incl. Tax

O-RING 21X2 NBR70

46811499

1,57 €(1,38 £)

Unit Price Incl. Tax

PISTON 6X27, 8X9 COMPRESSION

48600047

22,51 €(19,73 £)

Unit Price Incl. Tax

O-RING 4X1, 5 NBR70

50180222

1,27 €(1,11 £)

Unit Price Incl. Tax

PIN KIT

48600977S

12,04 €(10,55 £)

Unit Price Incl. Tax

NUT M6X0, 5 H6, 5 WAF10 REBOUND

40540486

4,36 €(3,82 £)

Unit Price Incl. Tax

GUIDING RING 39X44X8

48600744

7,20 €(6,31 £)

Unit Price Incl. Tax

SPRING GUIDE RING 27, 08X32X9, 5

48600577

8,77 €(7,69 £)

Unit Price Incl. Tax

WASHER 32X42X2, 5 PLASTIC

48600113

5,14 €(4,51 £)

Unit Price Incl. Tax

AXLE CLAMP LEFT + TUBE CPL.

48600863SA

375,64 €(329,25 £)

Unit Price Incl. Tax

AXLE CLAMP RIGHT + TUBE CPL.

48600864SA

Contact

HH COLLAR SCREW M8X25

0025080256

3,15 €(2,76 £)

Unit Price Incl. Tax

NUT VALVE M6X0, 5 H6, 5 WAF17

48600885

4,36 €(3,82 £)

Unit Price Incl. Tax

SPRING (8, 5) L6, 5 VALVE

48600202

4,36 €(3,82 £)

Unit Price Incl. Tax

TAP 6X38 COMPRESSION

48600509

12,04 €(10,55 £)

Unit Price Incl. Tax

PISTON 6, 07X22, 7X13

48600575

22,51 €(19,73 £)

Unit Price Incl. Tax

PISTON RING 21X23X5

48600455

48601625

3,93 €(3,44 £)

Unit Price Incl. Tax

RING D=23, 45X2, 65

48600296

10,41 €(9,12 £)

Unit Price Incl. Tax

SEAL RING FREUDENBERG 12MM 85S

48600829

5,69 €(4,99 £)

Unit Price Incl. Tax

SCREW SLEEVE M24, 5X1 CPL

48600760S

55,54 €(48,68 £)

Unit Price Incl. Tax

GUIDE BUSHING 12X14X10

48600430

7,20 €(6,31 £)

Unit Price Incl. Tax

CHECK VALVE LOCKING R4

48600709

14,76 €(12,94 £)

Unit Price Incl. Tax

ROUND-WIRE SNAP RING 24X2

48600446

3,03 €(2,66 £)

Unit Price Incl. Tax

SILICON PLUG 60SH

15080017

2,54 €(2,23 £)

Unit Price Incl. Tax

RUBBER CAP 26, 4X11

48600692

3,33 €(2,92 £)

Unit Price Incl. Tax

FORK OIL SAE4 5L

48600765S1

48601166S1

111,50 €(97,73 £)

Unit Price Incl. Tax

O-RING 43X2 NBR70 SILICONIZED

40140024

1,82 €(1,60 £)

Unit Price Incl. Tax

SCREW CAP L=125

48600516S1

48600516E1

92,26 €(80,87 £)

Unit Price Incl. Tax

CROSS FLAT HEAD SCREW M4X10

48600526

2,54 €(2,23 £)

Unit Price Incl. Tax

CLAMPING RING BLADDER 11, 31X22

48600514

25,83 €(22,64 £)

Unit Price Incl. Tax

FUCHS GREASE IPR (250G)

T511

T14034

34,97 €(30,65 £)

Unit Price Incl. Tax

FORK SERVICE KIT 48MM

R14019

RP10046T

100,85 €(88,40 £)

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Husqvarna. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the FRONT FORK (PARTS) of your Husqvarna FE 570 of 2011. Let us know if you have any questions.
