IGNITION SYSTEM FOR HUSQVARNA SVARTPILEN 401 2020

ELECTRIC STARTER MOTOR

Item numbers

28630002010

Contact

GASKET IGNITION COVER

93730040000

14,64 €(12,91 £)

Unit Price Incl. Tax

STATOR CMPL.

93739004100

195,17 €(172,06 £)

Unit Price Incl. Tax

ROTOR CPL.

90839005000

284,59 €(250,89 £)

Unit Price Incl. Tax

SCREW PLUG, OT MARKING

93839010000

10,65 €(9,39 £)

Unit Price Incl. Tax

O-RING 15, 8X2, 4

J770015824

1,21 €(1,07 £)

Unit Price Incl. Tax

PIN DOWEL 8X6, 4X14MM

90130024000

2,30 €(2,03 £)

Unit Price Incl. Tax

HH COLLAR SCREW M5X6

J025060083S

1,94 €(1,71 £)

Unit Price Incl. Tax

BRACKET HARNESS MAGNETO

90230062000

2,54 €(2,24 £)

Unit Price Incl. Tax

IGNISION COIL CMPL.

90239006044

93339006033

59,47 €(52,43 £)

Unit Price Incl. Tax

SEALING BOOT SPARK PLUG

93839091000

3,33 €(2,94 £)

Unit Price Incl. Tax

SPARK PLUG BOSCH VR6NEU M12X1.

93839093000

14,40 €(12,70 £)

Unit Price Incl. Tax

FRONT SPROCKET COVER

90230060002

15,79 €(13,92 £)

Unit Price Incl. Tax

HEX COLLAR SCREW M6X50

J025060506

1,69 €(1,49 £)

Unit Price Incl. Tax

HEX COLLAR SCREW M6X35

J025060353

1,69 €(1,49 £)

Unit Price Incl. Tax

O-RING 24X2, 5

J770024015

1,21 €(1,07 £)

Unit Price Incl. Tax

PLUG SCREW M24X1, 5

90230094000

10,65 €(9,39 £)

Unit Price Incl. Tax

BUSH STARTER SHAFT

90240018000

3,63 €(3,20 £)

Unit Price Incl. Tax

OIL NOZZLE

90230066300

5,69 €(5,02 £)

Unit Price Incl. Tax

ROTOR SCREW CPL.

90239005050

5,08 €(4,48 £)

Unit Price Incl. Tax

BOLT SOCKET M6X1XL22 BLK STEPE

93003082000

2,66 €(2,35 £)

Unit Price Incl. Tax

SOCKET HEAD BOLT M5X0, 8X40

90530002010

1,63 €(1,44 £)

Unit Price Incl. Tax

PLATE HARNESS MAGNETO

90230058000

6,41 €(5,65 £)

Unit Price Incl. Tax

PLATE HARNESS 2

93730059000

5,69 €(5,02 £)

Unit Price Incl. Tax

BOLT SOCKET M6X1

90130001001

J900000602013

1,69 €(1,49 £)

Unit Price Incl. Tax

DISTANCE BUSHING SPROCKET COVE

93003081000

4,30 €(3,79 £)

Unit Price Incl. Tax

BOLT FLANGE M6X16

J028060164

1,69 €(1,49 £)

Unit Price Incl. Tax

RETAINER GEAR STARTER

90240020002

4,05 €(3,57 £)

Unit Price Incl. Tax

HH COLLAR SCREW M6X35 TX30

0025060356

Contact

SUPPORT FREEWHEEL CLUTCH

90130001000

31,22 €(27,52 £)

Unit Price Incl. Tax

FREEWHEEL CLUTCH

90140026000

102,91 €(90,73 £)

Unit Price Incl. Tax

COVER, IGNITION COIL

28139006050

12,89 €(11,36 £)

Unit Price Incl. Tax

BUSHING IGNITION COIL COVER

28139006040

4,05 €(3,57 £)

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Husqvarna. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the IGNITION SYSTEM of your Husqvarna SVARTPILEN 401 of 2020. Let us know if you have any questions.
