GEARBOX MAIN SHAFT

GEARBOX COUNTERSHAFT FOR HVA FC 250 2014

GEAR SHIFTING MECHANISM

(7) 77733110100

COUNTERSHAFT

(8) 78033132000

TAB WASHER BEARING COUNT.SHAFT

(9) 0019050106S

HEX LOBE COUNTERSUNC SCREW M5X

(11) 77733316000

SHIFT COLLAR

(12) 77733012000

IDLER GEAR 2ND G. T=32

(13) 77733214000

IDLER GEAR 4.G. Z=26

(14) 77733215000

SLIDING GEAR 5.G.,Z=25

(15) 77733213000

IDLER GEAR 3.G. Z=28

(16) 0417024000

CIRCLIP WS24

(16) 0417024000

CIRCLIP WS24

(16) 0417024000

CIRCLIP WS24

(17) 79133111000

IDLER GEAR 1ST G. T=32

(20) 59033034044

SCREW 10.9+SPRING WASHER

(20) 59033034044

SCREW 10.9+SPRING WASHER

(21) 0405202612

NEEDLE BEARING K 20X26X12

(22) 0405242812

NEDDLE BEAR. K24X28X11,9 DIV.

(23) 0405222611

NEEDLE BEAR.K 22X26X10 DIVIDED

(23) 0405222611

NEEDLE BEAR.K 22X26X10 DIVIDED

(25) 49030023000

CYLINDRICAL ROLLER BEARING NJ2

(26) 0625062035

BALL BEARING 6203 JR2 C3

(28) 0471170015

CIRCLIP DIN 0471-17X1, 5

(29) 79233029013

FRONT SPROCKET 13-T

(29) 79233029014

FRONT SPROCKET 14-T

(30) 77733043000

STOP DISC 23,4X31X1,5

(30) 77733043000

STOP DISC 23,4X31X1,5

(31) 77233020000

STOP DISK 17,2X30X1,3

(32) 54633014100

SPACER BUSHING 12MM

(32) 54633014100

SPACER BUSHING 12MM

(33) 0760324571

SHAFT SEAL RING 32X45X7 BSLNBR

(33) 0760324571

SHAFT SEAL RING 32X45X7 BSLNBR

(35) 0770020220

O-RING 25,12X1,78 NBR70

(35) 0770020220

O-RING 25,12X1,78 NBR70

(41) 54833080000

STOP DISC 20,2X30X1

(43) 77733044000

STOP DISC 24X32X1,5

(99) 78033010010

COUNTER SHAFT REP.KIT 4 STROKE

	Part number	Description	Qty
# 7	77733110000 77733110100	COUNTERSHAFT	200,56 €(171,72 £)
# 8	78033132000	TAB WASHER BEARING COUNT.SHAFT	5,14 €(4,40 £)
# 9	0019050106S	HEX LOBE COUNTERSUNC SCREW M5X	2,06 €(1,76 £)
# 11	77733316000	SHIFT COLLAR	97,10 €(83,14 £)
# 12	77733012000	IDLER GEAR 2ND G. T=32	128,26 €(109,82 £)
# 13	77733214000	IDLER GEAR 4.G. Z=26	110,59 €(94,69 £)
# 14	77733215000	SLIDING GEAR 5.G., Z=25	128,26 €(109,82 £)
# 15	77733213000	IDLER GEAR 3.G. Z=28	110,59 €(94,69 £)
# 16	0417024000	CIRCLIP WS24	1,21 €(1,04 £)
# 17	77733011000 79133111000	IDLER GEAR 1ST G. T=32	145,99 €(125,00 £)
# 20	59033034044	SCREW 10.9+SPRING WASHER	4,66 €(3,99 £)
# 21	0405202612	NEEDLE BEARING K 20X26X12	8,23 €(7,05 £)
# 22	0405242812	NEDDLE BEAR. K24X28X11, 9 DIV.	8,23 €(7,05 £)
# 23	0405222611	NEEDLE BEAR.K 22X26X10 DIVIDED	8,23 €(7,05 £)
# 25	49030023000	CYLINDRICAL ROLLER BEARING NJ2	54,75 €(46,88 £)
# 26	0625062035	BALL BEARING 6203 JR2 C3	11,62 €(9,95 £)
# 28	0471170015	CIRCLIP DIN 0471-17X1, 5	1,21 €(1,04 £)
# 29	50033029013 79233029013	FRONT SPROCKET 13-T	17,00 €(14,56 £)
# 29	50033029014 79233029014	FRONT SPROCKET 14-T	17,00 €(14,56 £)
# 30	77733043000	STOP DISC 23, 4X31X1, 5	3,93 €(3,36 £)
# 31	77233020000	STOP DISK 17, 2X30X1, 3	3,93 €(3,36 £)
# 32	54633014100	SPACER BUSHING 12MM	17,06 €(14,61 £)
# 33	0760324571	SHAFT SEAL RING 32X45X7 BSLNBR	5,38 €(4,61 £)
# 35	0770020220	O-RING 25, 12X1, 78 NBR70	1,21 €(1,04 £)
# 41	54833080000	STOP DISC 20, 2X30X1	3,93 €(3,36 £)
# 43	77733044000	STOP DISC 24X32X1, 5	3,93 €(3,36 £)
# 99	00050000941 78033010010	COUNTER SHAFT REP.KIT 4 STROKE	29,95 €(25,64 £)
