CLUTCH FOR HVA TC 125 2022

GEARBOX MAIN SHAFT

(1) 50532001173

CLUTCH BASKET SX

(2) 50532002000

INNER CLUTCH HUB

(3) 50532013000

INNER RING

(4) 50532011000

FRICTION PLATE 1.95 MM

(5) 78032057044

PRESSURE PIECE

(6) 50532004100

SLEEVE 7.95X31.65

(7) 0025050206

HH COLLAR SCREW M5X20 TX30

(8) 50532006000

SPRING PLATE

(9) 50532005000

CLUTCH SPRING

(10) 0936181505

HEXAGON NUT DIN0936-M18X1,5 R.

(11) 78132018100

LOCKING PLATE

(12) 50532017000

SUPPORTING PLATE 20X36X2.5

(13) 0405263017

NEEDLE CAGE K263017

(14) 50532015000

COLLAR 20X26X19,5

(15) 50532023023

GEAR PRIMARY DRIVE

(16) 78032057044

PRESSURE PIECE CPL. 08

(17) 50532054000

PUSH ROD

(18) 0770300015

O-RING 30,00X1,50 NBR 70

(19) 79232061044

OUTPUT CYLINDER CPL.

(20) 0603082121

SEAL RING CU DIN7603- 8X12X1

(21) 79232063000

CLUTCH PIPE

(22) 79032064000

BLEEDER SCREW CPL.

(23) 0025060166

HH COLLAR SCREW M6X16 TX30

(24) 0025060256

HH COLLAR SCREW M6X25 TX30

(25) 50329050000

VENT INJEKTION HYDR. CLUTCH

(26) 0993012000

CIRCLIP DIN7993-RW12

(27) 54637098200

AXIAL WASHER AS1226 12X26X1

(28) 54637097200

AXIAL NEEDLE BEARING AXK 1226

(29) 50532003000

PREASURE PLATE

(99) 50532010033

CLUTCH DISC PACK

	Part number	Description	Qty
# 1	50532001073 50532001173	CLUTCH BASKET SX	310,12 €(265,60 £)
# 2	50532002000	INNER CLUTCH HUB	97,34 €(83,36 £)
# 3	50532013000	INNER RING	13,01 €(11,14 £)
# 4	50532011000	FRICTION PLATE 1.95 MM	17,00 €(14,56 £)
# 5	78032057000 78032057044	PRESSURE PIECE	26,62 €(22,80 £)
# 6	50532004100	SLEEVE 7.95X31.65	3,51 €(3,01 £)
# 7	0025050206	HH COLLAR SCREW M5X20 TX30	1,75 €(1,50 £)
# 8	50532006000	SPRING PLATE	29,58 €(25,33 £)
# 9	50532005000	CLUTCH SPRING	15,85 €(13,57 £)
# 10	0936181505	HEXAGON NUT DIN0936-M18X1, 5 R.	3,87 €(3,31 £)
# 11	78132018100	LOCKING PLATE	5,32 €(4,56 £)
# 12	50532017000	SUPPORTING PLATE 20X36X2.5	6,05 €(5,18 £)
# 13	0405263017	NEEDLE CAGE K263017	8,23 €(7,05 £)
# 14	50532015000	COLLAR 20X26X19, 5	24,87 €(21,30 £)
# 15	50532023023	GEAR PRIMARY DRIVE	118,04 €(101,09 £)
# 16	78032057044	PRESSURE PIECE CPL. 08	26,62 €(22,80 £)
# 17	50532054000	PUSH ROD	21,78 €(18,65 £)
# 18	0770300015	O-RING 30, 00X1, 50 NBR 70	1,51 €(1,29 £)
# 19	79232061044	OUTPUT CYLINDER CPL.	155,00 €(132,75 £)
# 20	0603082121	SEAL RING CU DIN7603- 8X12X1	1,33 €(1,14 £)
# 21	79232063000	CLUTCH PIPE	90,93 €(77,88 £)
# 22	79032064000	BLEEDER SCREW CPL.	17,06 €(14,61 £)
# 23	0025060166	HH COLLAR SCREW M6X16 TX30	1,75 €(1,50 £)
# 24	0025060256	HH COLLAR SCREW M6X25 TX30	1,75 €(1,50 £)
# 25	50329050000	VENT INJEKTION HYDR. CLUTCH	Contact	0,00 €(0,00 £)
# 26	0993012000	CIRCLIP DIN7993-RW12	1,21 €(1,04 £)
# 27	54637098200	AXIAL WASHER AS1226 12X26X1	3,15 €(2,70 £)
# 28	54637097200	AXIAL NEEDLE BEARING AXK 1226	7,26 €(6,22 £)
# 29	50532003000	PREASURE PLATE	65,64 €(56,22 £)
# 99	50532010033	CLUTCH DISC PACK	173,82 €(148,86 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Husqvarna. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the CLUTCH of your Husqvarna TC 125 of 2022. Let us know if you have any questions.
