GEAR SHIFTING MECHANISM FOR HVA TC 125 2016

WATERPUMP

(1) 50534005044

SHIFT SHAFT ASSY

(2) 61234008044

SLIDING PLATE

(3) 56534013100

TENSIONING SPRING 0,8MM

(4) 54634020000

SPRING GUIDE

(5) 54834014000

RETURN SPRING 03

(6) 54634050000

STOP DISK 14X30X1

(7) 54632095000

NEEDLE SLEEVE HK 1412 14X20X12

(7) 54632095000

NEEDLE SLEEVE HK 1412 14X20X12

(8) 0760142460

RADIAL SHAFT SEAL 14X24X6 B

(9) 79434031100

SHIFTING LEVER CPL.

(10) 50233041500

PAIR NORDLOCK WASHER M6

(11) 0024060156S

HH COLLAR SCREW M6X15 TX30

(12) 0025050206

HH COLLAR SCREW M5X20 TX30

(13) 0349000050

WASHER DIN7349-5X15X2

(14) 50334024144

LOCATING LEVER CPL. 08

(15) 54634052300

SLEEVE FOR LOCKING LEVER

(16) 54834023000

LOCKING LEVER SPRING 03

(18) 50434003000

SHIFTING FORK 1ST/3RD GEAR

(19) 50434002000

SHIFTING FORK 2ND/4TH GEAR

(20) 50434001000

SHIFTING FORK 5/6 GEAR

(21) 0402061480

NEEDLE ROLLER DIN5402 6X14,8

(21) 0402061480

NEEDLE ROLLER DIN5402 6X14,8

(21) 0402061480

NEEDLE ROLLER DIN5402 6X14,8

(22) 54834020000

SHIFT. RAIL C. SHAFT 250/300

(23) 54834019000

SHIFT. RAIL MAIN SHAFT 250/300

(24) 58038023200

PRESSURE SPRING 0,9MM

(24) 58038023200

PRESSURE SPRING 0,9MM

(24) 58038023200

PRESSURE SPRING 0,9MM

(25) 0012060303

AH SCREW DIN6912 M6X30 8.8

(26) 50434015100

SHIFT DRUM LOCATING CPL.

(27) 0625618050

BALL BEARING 61805 C3

(28) 50434012033

SHIFTING DRUM CPL.

(29) 0625069034

BALL BEARING 6903 C4

	Part number	Description	Qty
# 1	54834005133 50534005044	SHIFT SHAFT ASSY	97,71 €(83,45 £)
# 2	61234008044	SLIDING PLATE	18,39 €(15,71 £)
# 3	56534013100	TENSIONING SPRING 0, 8MM	2,12 €(1,81 £)
# 4	54634020000	SPRING GUIDE	5,14 €(4,39 £)
# 5	54834014000	RETURN SPRING 03	4,66 €(3,98 £)
# 6	54634050000	STOP DISK 14X30X1	3,93 €(3,36 £)
# 7	54632095000	NEEDLE SLEEVE HK 1412 14X20X12	4,42 €(3,77 £)
# 8	0760142460	RADIAL SHAFT SEAL 14X24X6 B	4,42 €(3,77 £)
# 9	79434031000 79434031100	SHIFTING LEVER CPL.	63,89 €(54,57 £)
# 10	50233041500	PAIR NORDLOCK WASHER M6	2,78 €(2,37 £)
# 11	0024060156S	HH COLLAR SCREW M6X15 TX30	2,06 €(1,76 £)
# 12	0025050206	HH COLLAR SCREW M5X20 TX30	1,75 €(1,49 £)
# 13	0349000050	WASHER DIN7349-5X15X2	0,91 €(0,78 £)
# 14	50334024144	LOCATING LEVER CPL. 08	21,60 €(18,45 £)
# 15	54634052300	SLEEVE FOR LOCKING LEVER	4,48 €(3,83 £)
# 16	54834023000	LOCKING LEVER SPRING 03	4,05 €(3,46 £)
# 18	50434003000	SHIFTING FORK 1ST/3RD GEAR	66,25 €(56,58 £)
# 19	50434002000	SHIFTING FORK 2ND/4TH GEAR	66,25 €(56,58 £)
# 20	50434001000	SHIFTING FORK 5/6 GEAR	66,25 €(56,58 £)
# 21	0402061480	NEEDLE ROLLER DIN5402 6X14, 8	1,57 €(1,34 £)
# 22	54834020000	SHIFT. RAIL C. SHAFT 250/300	15,43 €(13,18 £)
# 23	54834019000	SHIFT. RAIL MAIN SHAFT 250/300	13,01 €(11,11 £)
# 24	58038023200	PRESSURE SPRING 0, 9MM	5,93 €(5,06 £)
# 25	0012060303	AH SCREW DIN6912 M6X30 8.8	1,21 €(1,03 £)
# 26	50434015033 50434015100	SHIFT DRUM LOCATING CPL.	51,43 €(43,92 £)
# 27	0625618050	BALL BEARING 61805 C3	16,21 €(13,84 £)
# 28	50434012033	SHIFTING DRUM CPL.	112,65 €(96,21 £)
# 29	0625069034	BALL BEARING 6903 C4	11,62 €(9,92 £)
